Preliminary procedures
After having installed the device, it must be programmed, giving it
an identication number (ID), which is unique for each appliance.
The BASIC programming is described below, which can be done
with the device's keyboard.
All programming operations must be performed with the indoor
unit on standby.
For ADVANCED programming, use the SaveProg software for PC.
Programming ID identication code
The identication code is programmed with a congured MASTER
entrance panel.
An indoor unit with no ID code programming beeps three times when
the button is pressed
1) Lift the handset and place to the ear.
2) Press the
and buttons simultaneously and keep them
pressed until the
button starts blinking.
3) Release the buttons.
4) Press the button within 5s of releasing the buttons and keep
it pressed until you hear a warning tone on the handset and the
communication is activated between the indoor unit and the ex-
ternal electronic unit. If more than 5s passes without the
button being pressed, steps 1, 2 and 3 must be repeated.
5) Release the button.
6) Within 25s, pair the ID code from the external electronic unit, fol-
lowing the procedure described on the speech unit (pushing a
button, internal keyboard entry).
NOTE: If the installation already contains an indoor unit with the
same paired identication code, the entrance panel will emit a tone
and the process must be repeated from the start in order to assign
a different code.
Programming secondary ID
The secondary identication code is programmed when the same
call has to activate multiple indoor units at the same time (max 4
composed of 1 Master and 3 secondary ones). You need to dene a
Master indoor unit which can be paired with up to 3 indoor units with
a secondary ID. At most 50 Master ID codes can be programmed
in this way.
1) Lift and place to the ear the handset of the indoor unit.
2) Press the
and buttons simultaneously and keep them
pressed until the
button starts blinking.
3) Release the buttons.
4) Press the and buttons simultaneously within 5s of re-
leasing the buttons and keep them pressed until you hear a warn-
ing tone on the indoor unit and the communication is activated
between the indoor unit and the external electronic unit. If more
than 5s passes without the
and buttons being pressed,
steps 1, 2 and 3 must be repeated.
5) Release the and buttons.
6) Within 25s, pair the ID code of the Master from the electronic unit,
following the procedure described on the speech unit (pushing a
button, internal keyboard entry).
Note: Use the SaveProg software to program chime activation of all
the monitors and switching on only the master monitor.
Note: To delete from a group, the programming deletion procedure
described in the “Default data restore procedure” section must be
performed.
Button programming for intercom calls
1) Raise and place to the ear the handset of the indoor unit to pro-
gram (caller).
2) Press the
and buttons of the indoor unit to program (call-
er) and keep them pressed until the button starts blinking.
3) Release the buttons.
4) Press and hold down the
button.
5) Wait for the indoor unit to emit a continuous tone.
6) Release the button.
7) Press a button on the indoor unit to call (
/F1/F2/ ).
8) An audible warning on the calling indoor unit conrms that the
procedure has correctly completed.
Programming the self-start button for a specic
electronic unit
1) Lift the handset and place to the ear.
2) Press the
and buttons simultaneously and keep them
pressed until the
button starts blinking.
3) Release the buttons.
4) Press and hold down the
button.
5) Wait for the indoor unit to emit an audible warning.
6) Release the button.
7) Call the indoor unit from the entrance panel on which you want
direct self-starting (pressing a button, internal keyboard entry or
selecting the name from the contacts list).
8) At the end of the procedure described above, the indoor unit emits
a signal to conrm that the operation has been successful and it is
called by the entrance panel.
Procedure for restoring default programming for
the button
1) Lift the handset and place to the ear.
2) Press the
and buttons simultaneously and keep them
pressed until the
button starts blinking.
3) Release the buttons.
4) Press and hold down the
button until the indoor unit beeps.
5) Release the button and press the button again, the indoor unit
emits a signal to conrm that the operation has been successful.
Note: to reprogramme buttons
and use the SaveProg
software.
Programming procedure for the levels of contrast
and brightness of the LCD
1) Lift the handset and place to the ear.
2) Press the
and buttons simultaneously and keep them
pressed until the
button starts blinking.
3) Release the buttons.
4) Press one of the 4 buttons beneath the handset:
, , ,
. Self-starting is performed on the rst programmed speech
19
TAB: 7548
EN
