unit (by default the Master).
5) Adjust the brightness with the
and buttons and adjust the
contrast with the
or buttons.
6) You exit the procedure with a time out (Conversation time) or by
hanging up the micro-telephone.
Default data restore procedure
1) Lift the handset and place to the ear.
2) Press the
and buttons simultaneously and keep them
pressed until the
button starts blinking.
3) Release the buttons.
4) Press and hold down the
button.
5) When an audible warning is emitted (during the sound) release the
button and briey press the button.
The indoor unit programming has now been deleted. Make sure that
the programming has been successfully deleted by pressing the
button. The indoor unit should emit an audible warning (3
beeps).
User congurations
These operations are to be done with the indoor unit on standby
and the handset hung up.
Selecting panel call tunes
10 different chime tunes can be selected.
1) Press and hold down the
button (for 2 s) until the button starts
blinking accompanied by an audible warning.
2) Press button
and the internal unit will start playing the last
tune stored.
3) Repeatedly press button
to select the kind of tune you want.
4) Press the
button to save the tune or wait 15s. At the end of
conguration, the blinking button goes out.
Chime volume adjustment
The chime volume can be set to 10 levels.
1) Press and hold down the button (for 2 s) until the but-
ton starts blinking accompanied by an audible warning.
2) Press button
to decrease or to increase the chime vol-
ume. Each time the buttons are pressed the volume changes by
one level.
3) After selecting the required volume, press button
to store
the level or wait 15s. At the end of conguration, the button
stops blinking.
Muting the chime
To mute the chime, press the button and hold it down (approx-
imately 2s). Deactivation is conrmed with a "low-pitched" tone and
the
button lighting up with a steady light. Chime reactivation is
signalled by a "high-pitched" tone and the
button going out. The
indoor unit is able to keep up to 4 missed calls in memory by blinking
the
button. Saving to memory consists of one ash per missed
call. When the chime is restored the counter is reset. This function
can be activated with the indoor unit at rest.
Adjustments (during a conversation)
Brightness adjustment (10 levels with indoor unit in
a conversation)
Adjustment is possible during communications and self-starting,
press the
and buttons (underneath the handset) to adjust
the brightness.
External call voice unit volume adjustment (10 lev-
els with indoor unit in a conversation)
Use the and buttons (underneath the handset) to adjust
the desired level. A beep is emitted on reaching the maximum or
minimum level.
It is adjusted during a conversation.
Internal call voice unit volume adjustment (10 levels
with indoor unit in a conversation)
Use the and buttons (underneath the handset) to adjust
the desired level. A beep is emitted on reaching the maximum or
minimum level.
It is adjusted during a conversation.
Operation
Caution: For the indoor station to work, the ID code must have al-
ready been congured. To check this, press a button on the monitor
(but not the volume and brightness buttons): if an ID has been as
-
signed to the monitor, one beep will sound, if no ID has been as-
signed or it has been deleted, 3 beeps will sound.
Answering a call
A call from the outdoor entrance panel or from an intercommuni-
cating device can be answered during the chime cycle or once it
has ended. To answer, lift the handset; to end the call, replace the
handset.
FP/M Landing calls (see "FP/M connection variant"
wiring diagrams)
The duration of the chime cycle depends on how long the button is
pressed, for a maximum time of 10s.
Making an intercommunicating call
To make a call to another indoor unit, one or more buttons must
have been programmed (see “Button conguration” section). Raise
the handset and press the programmed button for the indoor unit to
call. During the call, the indoor unit emits a tone in order to signal
that the call is being made. If the indoor unit is already engaged with
another call, a tone will be heard on the indoor unit making the call
to indicate that the user receiving the call is busy. When the called
party answers, the communication is automatically activated. Hang
up to end the conversation. The maximum length of a conversation is
5 minutes (unless programmed otherwise with SaveProg).
Temporarily muting the chime (Mute)
20
