35
RIF CODICE QTA' DESCRIZIONE
30 2894784.2 2 SUPPORTO PEDANA
31 2255424 1 MICRO + GUAINA
32 23041010 1 LAMIERA MICRO SX
33 5214099 2 PIASTRINA
34 1714185 1 MOT. 0.75KW 220V MONOF.V64CS
35 4502024 1 FRENO TEMP. KF1-G95 4.5 Nm
36 2255445 1 MICRO
37 6012016 1 RID. MOTOVARIO NMRV 50 1/80
38 6734017 2 CATENA
39 0904302 1 DISTANZIALE
40 0714146 1 MOLLA SUPPORTO MICRO
41 4664066 1 PATTINO MICRO CATENA
42 23041289 1 LAMIERA SUPP. MICRO CATENA
43 1304273 1 PERNO GUIDA SUPP. MICRO
44 1334108 1 BOCCOLA
45 2864889 1 STAFFA
FRAME
PLATFORM SUPPORT
MICROSWITCH + SHEATH
LH MICROSWITCH SHEET PLATE
PLATE
MOTOR 0.75KW 220V SINGLE-PHASE V64CS
BRAKE TEMP. KF1-G95 4.5 Nm
MICROSWITCH
MOTOVARIATOR-GEAR REDUCER NMRV 50 1/80
CHAIN
SPACER
MICROSWITCH SUPPORT SPRING
CHAIN MICROSWITCH GUIDE SHOE
CHAIN MICROSWITCH SUPP. SHEET PLATE
MICROSWITCH SUPP. RAIL PIN
BUSH
BRACKET
DESCRIPTION
