42
RIF CODICE QTA' DESCRIZIONE
18 0714143 4 MOLLA INOX 19 0012268 4 SPINA DIRITTA ELASTICA 20 0011024 1 VITE 21 0012371 24 ROSETTA 22 0010005 12 DADO 23 0010386 12 VITE 24 0010896 4 VITE 25 2304113 4 LAMIERA MICRO 26 0010999 8 VITE 27 0010887 8 VITE 28 1304130 1 PERNO B. ACC. FRONT. L= 1050 29 2594396 2 PROTEZIONE 30 2874167 4 COPERCHIO BANDELLA 31 4354020.1 1 ACC.FRONTALE L= 1050 32 1304211 2 PERNO BANDELLA ACC. FRON. 33 4404039 1 CERNIERA LATO FOLLE 34 0714154 4 MOLLA PER DOPPIO FONDO DX 35 2894832 4 SUPP. BANDELLA ACC. FRONT. 36 4404038 1 CERNIERA BANDELLA 37 3334023 2
BLOCCO CINGHIA ACCESS. FRON.
38 4354057.1 1 ACC. FRONT. MOBILE L=1050 38 4354056.1 1 ACC. FRONT. MOBILE L=1250 39 1332005 2 BOCCOLA 40 2904129.3 1 LEVA RINVIO CINGHIA ACC. FR. V 41 1304209 1 PERNO ROTAZIONE PEDANA 41 1304212 1 PERNO ROTAZIONE PEDANA 42 0784032 1
FASCIA DI SOLLEV. BANDELLA L=900
42
0784029 1
FASCIA DI SOLLEV. BANDELLA L=800
42 0784014 1
FASCIA DI SOLLEV. BANDELLA L=770
42
0784013 1
FASCIA DI SOLLEV. BANDELLA L=700
43
0714155 1 MOLLA PER DOPPIO FONDO SX
44 0714050 1 MOLLA 45 1304390 1
PERNO AZIONAM. MICRO BANDELLA
46 2504194 1 SUPP. BANDELLA ACC. FRONT. 47 3714079 1 SUPP. BANDELLA ACC. FRONT. 48 2594646 1 PROTEZIONE 49 0010948 4 VITE
PLATFORM
STAINLESS STEEL SPRING STRAIGHT ELASTIC PIN SCREW WASHER NUT SCREW SCREW MICROSWITCH SHEET PLATE SCREW SCREW FRONT ACC. GUARD BOARD PIN L=1050 PROTECTION GUARD BOARD COVER FRONT ACCESS L=1050 FRONT ACC. GUARD BOARD PIN IDLE SIDE HINGE SPRING FOR RIGHT BOTTOM SAFE EDGE FRONT ACC. GUARD BOARD SUPP. GUARD BOARD HINGE FRONT ACCESS BELT LOCK MOVABLE FRONTAL ACCESS L=1050 MOVABLE FRONTAL ACCESS L=1250 BUSH FRONT ACCESS BELT TRANSMISSION LEVER FOOTBOARD ROTATION PIN FOOTBOARD ROTATION PIN GUARD BOARD LIFTING BAND L=900 GUARD BOARD LIFTING BAND L=800 GUARD BOARD LIFTING BAND L=770 GUARD BOARD LIFTING BAND L=700 SPRING FOR LEFT BOTTOM SAFE EDGE SPRING GUARD BOARD MICROSWITCH DRIVE PIN FRONT ACC. GUARD BOARD SUPP. FRONT ACC. GUARD BOARD SUPP. PROTECTION SCREW
DESCRIPTION
