vimec V 64 - Page 49

49
RIF CODICE QTA' DESCRIZIONE
27 0010210 1 VITE TE ISO 4014-M6x60
28 0714093 1 MOLLA ANTISC.
29 2894956 1 SUPP. MICRO VERSIONE 600
30 2504159 1 CAMMA FINECORSA VERS. 600
31 1304199 1 PERNO
32 0010033 1 DADO
33 3494214 1 PIGNONE
33A 3494213 1 PIGNONE
34 0714106 1 MOLLA
35 2254946 1 GUAINA MICRO SQ9-SQ10
36 0714094 2 MOLLA
37 2894816 2 SUPPORTO MICRO
38 2304457 1 LAMIERA SUPPORTO DX
38 2304477 1 LAMIERA SUPPORTO SX
39 0010537 2 VITE
40 2304478 1 PIASTRINA
41 0094061 1 ROSETTA
42 0010486 1 VITE
43 1712046 1 MOTORE
44 2304456 1 LAMIERA MOT. DX V65
44 2304480 1 LAMIERA MOT. SX V65
45 2904129 1 LEVA RINVIO SBLOCCO SX
45 2904127 1 LEVA RINVIO SBLOCCO DX
46 6734030 1
CATENA COMPL. DX PER BAR.RETR.
46 6734032 1
CATENA COMPL. SX PER BAR.RETR.
47 0012933 2 ANELLO
48 3494212 1 PIGNONE
49 1304198 1 PERNO
50 0012380 1 ROSETTA
51 0010296 1 VITE
52 2255061 1 GUAINA MICRO DX SQ5
52 2255062 1 GUAINA MICRO SX SQ6
RETRACTABLE SAFETY BARS
SCREW TE ISO 4014-M6x60 ANTISLIP SPRING MICRO SUPPORT VERSION 600 LIMIT SWITCH CAM VERSION 600 PIN NUT PINION PINION SPRING MICRO SHEATH SQ9-SQ10 SPRING MICROSWITCH SUPPORT RH SUPPORT SHEET PLATE LH SUPPORT SHEET PLATE SCREW PLATE WASHER SCREW MOTOR RH MOTOR SHEET PLATE V65 LH MOTOR SHEET PLATE V65 LEFT TRANSMISSION RELEASE LEVER RH TRANSMISSION RELEASE LEVER RH COMP. CHAIN FOR RETRACT.BAR LH COMP. CHAIN FOR RETRACT.BAR RING PINION PIN WASHER SCREW RH MICRO SHEATH SQ5 LH MICRO SHEATH SQ6
DESCRIPTION
