38
Vincent
Frequency response: 20 Hz - 20 kHz ± 0.1 dB
Nominal Output Voltage: 3 V
Total Harmonic Distortion: < 0.001 % (1 kHz, output voltage
2 Veff on 100 kΩ)
Amplifying: typ 13.3 dB (Volume control max. Gain)
Input sensitivity: 430 mV (for 2 V output voltage)
Signal to Noise Ratio: > 90 dB
Intermodulation ratio (DIN IEC268): >100 dB (60 Hz / 7 kHz, 4:1)
Input Impedance: 22 kΩ
AC power connection type: 230 V/50 Hz
Inputs: 6 x analog RCA stereo (LINE IN)
1 x digital optical
1 x digital coaxial
Outputs: 2 x RCA stereo (PRE OUT),
1 x RCA stereo (REC OUT)
Dimensions (W x H x D): 430 x 135 x 370 mm
Weight: 8.5 kg
Colour: silver / black
Tubes: 4 x CV6189; 4 x 6S3P-EV; 1 x 85A2
TECHNICAL SPECIFICATIONS
SEARCH FOR ERRORS
Symptom Possible Cause Countermeasure
Poor sound quality
The cable connections are not tight, the con-
nectors are dirty or a cable is defective.
A record player has been connected to a line
level input without using a phono preamplifier.
Check the cables and cable connections.
Interconnect a phono preamplifier.
The remote control
cannot perform any
functions
No batteries inserted in the remote control,
batteries are not inserted correctly or are
depleted.
The line-of-sight between the remote control
and the unit is obstructed, the range was
exceeded or the hand unit was operated from
a position too far to one side.
The unit is not switched on.
Check and replace the batteries if necessary.
Try to point the remote control at the front of
the unit only when the sight-line is clear, wit-
hin a 7-metre distance and, if possible, facing
the unit.
Switch on the unit.
Humming low fre-
quency noise is audi-
ble, even as no
audio source is play-
ing back
See section “Net frequency noise” in the
chapter “Tips”.
See section “Net frequency noise” in the
chapter “Tips”.
