13.Dismount the bottom hinge pin and t it
on the opposite side.
Note: The bush must also be moved.
12. Pull the LED wires gently out of the bot-
tom hinge pin.
14.Turn the door, so the glass side is down
(Note: Place something between the
glass and the other surface (cabinet) so
scratch are minimized).
Then loosen the gasket on the low end of
the door by pulling.
15. Pull the LED wires up and out.
