10.Unscrew the lock pin (using the at-hea-
ded screwdriver) and remove it.
8. Lift the bottom sheet metal part and turn
the glass so the lock hole ts the other
ends round Ø hole concentric. Place the
sheet metal part on the glass again, and
mount the brackets onto the plastic pro-
le in each end again. Don’t over tighten
the screws.
Note: The nut has to t into the centre
groove.
11.Pull up the lock cylinder and ret both
lock cylinder and lock pin in opposite
side.
9. The door has to be moved up from the
hinge.
