27.Dismount the top door bushing and
mount it on opposite side.
28.Dismount the plastic caps on the top of
the cabinet and mount them on opposite
side.
29.Make sure that the door is aligned with
the cabinet before mounting the top
hinge.
30. Remount the bottom front cover. Place
the unit vertically again and mount the
tow screws (see under # 1).
Note: Important: Wait approx. ½ hour
before connecting the unit to the main
grid.
Note: If the door LEDs don’t give out light
but the top LED in the cabinet is shin-
ing, it’s most likely that the wires are not
mounted correctly into the connector.
(See under # 6 & 25)
