Installation Installation
Installation
2) Select a location on the windshield rear of the rear-view mirror.
Front Camera Installation
1) Insert the clips, then slide the mount horizontally into the slot on
the back of the camera.
3) Wipe clean the installation surface of the windscreen with a dry
cloth, it must be grease free for the sticky pad to stick firmly.
4) Peel the protection film o the sticky pad and camera lens.
9 10
Connect to car
cigarette lighter socket
Best mounting location
Rear Camera Installation
5) Fix the front camera on the selected location.
6) Adjust the lens angle
- Look at the live view on the LCD.
- Adjust the angle of the lens up / down if necessary.
1) Select an installation location
2) Wipe clean the installation surface of the windscreen with a dry cloth.
Select a location on the windscreen, without defrosting grid
wires, and where the camera can record the entire rear view.
