Viofo T130 - Optional Accessories; Product Diagram

1. GPS Module
2. Reset Hole
3. microSD Card Slot
4. Front Rotatable Lens
5. Interior Rotatable Lens
6. Power On | OFF
Recording Start | Stop
7. Microphone On | OFF
8. Wi-Fi On | OFF
9. Video Protect
10. Rear Camera Port
11. Power In / microSD Card Reader
Mode (computer)
12. Recording Status Indicator
13. Microphone Status Indicator
14. Wi-Fi Status Indicator
15. GPS Status Indicator
16. Heat-dissipation Block
(Don't touch this block)
Optional Accessories
Product Diagram
Front Camera (Main Unit)
VIOFO Hardwire Kit for Car Dash Camera
INPUT:
RED
— POWER
BLACK
— GND
YELLOW
— ACC
Input: 12 / 24V; Output: 5V2A Max
43
Rear Camera
Circular Polarizing
Lens Filter
Bluetooth Remote
HK4
Hardwire Kit
Rear Camera
USB Cable (6M)
6
5
2
1
3
4
7
8
9
10
16
12
11
13
14
15
