2. Select a location on the windshield behind the rear-view mirror where the
camera will not obstruct the driver’s view while driving.
3. Wipe clean the installation surface of the windscreen with a dry
cloth, it must be grease free for the sticky pad to stick firmly.
4. Peel the protection film off the sticky pad and camera lens.
5. Fix the front camera on the selected location.
6. Adjust the lens angle
Adjust the angle of the lens up / down if required. The Interior Rotatable
Lens can also be rotated left and right.
Never try to rotate the lens completely. Cameras destroyed by too
much rotation of the lens are out of warranty.
7. Connecting to Power.
Plug the USB power adapter into your vehicle’s 12V / 24V female
power socket. Insert the 4M USB cable’s male connector into the
camera mount's USB Type-C port.
8. Layout after front camera installation and power connection:
2
109
Connect to car
cigarette lighter socket
Best mounting location
1
To Next Page
