Blue: Turned on/Working normally/Fully charged/Wi-Fi Connected
Breathing yellow: Charging
Blinking red: Error
Installation
1. Connect the charging dock to the power outlet.
3. Place the charging dock on a level ground against a wall.
2. Install the side brush on the upper-le corner of the vacuum-mop, as
shown in the figure. An extra side brush in the package is provided as a
spare and does not need to be installed.
4. When using the vacuum-mop for the first time, press and hold the
buon for 3 seconds to turn on the vacuum-mop. Once the
indicator lights up, manually place the vacuum-mop onto the
charging dock to charge. Then just press the buon when the
vacuum-mop is cleaning, it will automatically go to the charging
dock to recharge.
05
0.5 meters
0.5 meters
1.5 meters
