Section 4: Stand Installation
Keep the foam underneath the monitor before attaching the stand.
1. Open the package, take out the product with foam still attached, and gently place
it on a desktop or table.
Monitor
Stand Base
Foam
Stand Stem
2. Take out the two parts of the stand, and remove the foam covering the back of the
monitor. Next, insert the stand stem into the opening on the back of monitor then
use the included screwdriver and two NO.1 screws to fasten it to the monitor.
Stand Stem
NO.1 Screws
6mm x 2
3. Use the NO.2 screw to fasten the base to the stem.
NO.2 Screw
14mm x 1
Base
4. Make sure the stand is securely attached to the back of the monitor then remove
the monitor from the remaining foam and stand it up on a table or desk.
