Order no. 315-2AG13
I²t 0.5 A²s
Max. current drain at backplane bus 2.5 A
Power loss 6 W
Load and working memory
Load memory, integrated 2 MB
Load memory, maximum 2 MB
Work memory, integrated 1 MB
Work memory, maximal 2 MB
Memory divided in 50% program / 50% data
ü
Memory card slot MMC-Card with max. 1 GB
Hardware configuration
Racks, max. 4
Modules per rack, max. 8 in multiple-, 32 in a single-rack configuration
Number of integrated DP master 1
Number of DP master via CP 4
Operable function modules 8
Operable communication modules PtP 8
Operable communication modules LAN 8
Command processing times
Bit instructions, min. 0.01 µs
Word instruction, min. 0.01 µs
Double integer arithmetic, min. 0.01 µs
Floating-point arithmetic, min. 0.06 µs
Timers/Counters and their retentive charac-
teristics
Number of S7 counters 512
S7 counter remanence adjustable 0 up to 512
S7 counter remanence adjustable C0 .. C7
Number of S7 times 512
S7 times remanence adjustable 0 up to 512
S7 times remanence adjustable not retentive
Data range and retentive characteristic
Number of flags 8192 Byte
Bit memories retentive characteristic adjustable adjustable 0 up to 8192
Bit memories retentive characteristic preset MB0 .. MB15
Number of data blocks 4095
VIPA System 300S CPUHardware description
Technical data
HB140 | CPU | 315-2AG13 | GB | Rev. 14-40 32
