VIPA 315SB/DPM - Page 33

Order no. 315-2AG13
Max. data blocks size 64 KB
Number range DBs 1 ... 4095
Max. local data size per execution level 1024 Byte
Max. local data size per block 1024 Byte
Blocks
Number of OBs 23
Maximum OB size 64 KB
Total number DBs, FBs, FCs -
Number of FBs 2048
Maximum FB size 64 KB
Number range FBs 0 ... 2047
Number of FCs 2048
Maximum FC size 64 KB
Number range FCs 0 ... 2047
Maximum nesting depth per priority class 8
Maximum nesting depth additional within an
error OB
4
Time
Real-time clock buffered
ü
Clock buffered period (min.) 6 w
Type of buffering Vanadium Rechargeable Lithium Batterie
Load time for 50% buffering period 20 h
Load time for 100% buffering period 48 h
Accuracy (max. deviation per day) 10 s
Number of operating hours counter 8
Clock synchronization
ü
Synchronization via MPI Master/Slave
Synchronization via Ethernet (NTP) no
Address areas (I/O)
Input I/O address area 8192 Byte
Output I/O address area 8192 Byte
Process image adjustable
ü
Input process image preset 256 Byte
Output process image preset 256 Byte
Input process image maximal 2048 Byte
Output process image maximal 2048 Byte
VIPA System 300S CPU Hardware description
Technical data
HB140 | CPU | 315-2AG13 | GB | Rev. 14-40 33
