Order no. 315-2AG13
Digital inputs 65536
Digital outputs 65536
Digital inputs central 1024
Digital outputs central 1024
Integrated digital inputs -
Integrated digital outputs -
Analog inputs 4096
Analog outputs 4096
Analog inputs, central 256
Analog outputs, central 256
Integrated analog inputs -
Integrated analog outputs -
Communication functions
PG/OP channel
ü
Global data communication
ü
Number of GD circuits, max. 8
Size of GD packets, max. 54 Byte
S7 basic communication
ü
S7 basic communication, user data per job 76 Byte
S7 communication
ü
S7 communication as server
ü
S7 communication as client -
S7 communication, user data per job 160 Byte
Number of connections, max. 32
Functionality Sub-D interfaces
Type X2
Type of interface RS485
Connector Sub-D, 9-pin, female
Electrically isolated
ü
MPI
ü
MP²I (MPI/RS232) -
DP master -
DP slave -
Point-to-point interface -
Type X3
VIPA System 300S CPUHardware description
Technical data
