VIPA 315SB/DPM - Functionality PROFIBUS master

Order no. 315-2AG13
Type of interface RS485
Connector Sub-D, 9-pin, female
Electrically isolated
ü
MPI -
MP²I (MPI/RS232) -
DP master yes
DP slave yes
Point-to-point interface
ü
Functionality MPI
Number of connections, max. 32
PG/OP channel
ü
Routing
ü
Global data communication
ü
S7 basic communication
ü
S7 communication
ü
S7 communication as server
ü
S7 communication as client -
Transmission speed, min. 19.2 kbit/s
Transmission speed, max. 12 Mbit/s
Functionality PROFIBUS master
PG/OP channel
ü
Routing
ü
S7 basic communication
ü
S7 communication
ü
S7 communication as server
ü
S7 communication as client -
Activation/deactivation of DP slaves
ü
Direct data exchange (slave-to-slave communi-
cation)
-
DPV1
ü
Transmission speed, min. 9.6 kbit/s
Transmission speed, max. 12 Mbit/s
Number of DP slaves, max. 124
Address range inputs, max. 8 KB
Address range outputs, max. 8 KB
User data inputs per slave, max. 244 Byte
VIPA System 300S CPU Hardware description
Technical data
HB140 | CPU | 315-2AG13 | GB | Rev. 14-40 35
