1 Slot for SD storage medium
2 "Host"-USB-A interface
3 RJ45 jack for Ethernet communication LAN 1
4 RJ45 jack for Ethernet communication LAN 2
Please note that these two Ethernet interfaces cannot be
used as a Switch!
1 RS232 interface COM 1
2 RS232/RS422/RS485 interface COM 2
3 MPI/PROFIBUS DP interface COM 3 (optional)
4 Slot for DC 24V voltage supply
Please make sure that the Touch Panel always has to be
supplied with external voltage!
Side view
Bottom view
VIPA HMI Touch PanelHardware description
Structure > Overview
HB160 | TP-ECO | 62K-NHC0 | GB | 14-27 12
