VIPA TP 610LC - Nhc0-Cb

Order no. 62K-NHC0-DH
Reverse polarity protection
ü
Current consumption (no-load operation) 0.24 A
Current consumption (rated value) 1.36 A
Inrush current 85 A
I²t 0.34 A²s
Power loss 15 W
Status information, alarms, diagnostics
Supply voltage display none
Mechanical data
Housing / Protection type
Material aluminum, galvanized steel
Mounting mounting clips
Protect type front side IP 65
Protect type back side IP 20
Dimensions
Front panel 325 mm x 263 mm x 6 mm
Rear panel 310 mm x 248 mm x 50 mm
Installation cut-out
Width 311 mm
Height 249 mm
Minimum 2.5 mm
Maximum front panel thickness 6 mm
Weight 3350 g
Environmental conditions
Operating temperature 0 °C to 50 °C
Storage temperature -20 °C to 60 °C
Certifications
UL508 certification yes
2.6.2 62K-NHC0-CB
Order no. 62K-NHC0-CB
Type Touch Panel TP 610LC+
Display
Display size (diagonal) 10 "
Display size (width) 203 mm
VIPA HMI Touch Panel Hardware description
Technical data > 62K-NHC0-CB
HB160 | TP-ECO | 62K-NHC0 | GB | 14-27 21
