Via mode the interface could be set up on "DP slave".
The use of the optional MPI/PROFIBUS interface is
required.
4.7 Integrated Server
4.7.1 General
The Touch Panel has several integrated server that enable a remote
maintenance within a network. Some servers only allow access by
means of entering User name and Password. The following login data
are used standardly:
User name: wince
Password: vipatp
Per default the following server are integrated:
n ftp server (activated)
n http server (activated)
n Telnet (activated)
n VNC (not activated)
Phrases that are used in the description of the server:
A client is an application that uses the service of a server within a net-
work. For example, a web browser is a client because at every call of
a website it sends a request to a web server and receives an answer.
Login data
Overview
Phrases
Client
VIPA HMI Touch Panel Deployment under Windows CE 6.0 Prof.
Integrated Server> General
HB160 | TP-ECO | 62K-NHC0 | GB | 14-27 59
