As many components of the Control Panel conform with the system
control of Windows
Ò
, most of the description is not necessary. The
description of the control panel components relevant for operating the
Touch Panel can be found in the following:
n Set display
Via ‘Start è Settings è Control Panel è Display’ the dialog win-
dows for the display properties opens. Here you can change the
settings for the monitor options. For example you can adjust the
brightness via the register ‘Backlight è Advanced’.
n Calibrate touch screen
If the touch screen does not always react to a double click or not
precisely recognize the position of an entry, you can call the
dialog Stylus via ‘Start è Settings è Control Panel’. In the reg-
ister Double-Tap you can use the grid pattern to preset a double
click velocity and test this on the symbol below. Click [OK] to
accept the value. The calibration of the touch screen is completed
via the register Calibration by following the instructions.
n Set Ethernet parameters
The dialog field for pre-setting an Ethernet address is to be found
at ‘Start è Settings è Network and Dial-up Connections’. The
default setting is address assignment via DHCP.
Please consider with the manual assignment of IP
addresses that these are not identical for both interfaces. If
you accidentally have assigned to the same IP address to
both interfaces, then only one interface icon is shown at
‘Network and Dial- up Connections’ . By switching to
DHCP, you receive 2 Interface icons again and can con-
figure them individually.
n System properties (System)
Here you receive information about the version of the current Win-
dows
Ò
operating system, the memory load and sharing (altera-
tions here are not accepted into the registry) and the copyright.
The register Device Name allows you to change the device name
that is shown during Ethernet communication for instance.
To configure the optional MPI/DP interface on the Touch Panel start
via ‘Start è Settings è Control Panel’ or via "Settings" in the VIPA
Startup-Manager the tool "MPI/DP Slave Configuration".
Default: MPI - Address 1
The following settings are only required if not communicate via
Movicon.
System setting (Control
Panel)
Configuration MPI/DP
slave
VIPA HMI Touch PanelDeployment under Windows CE 6.0 Prof.
Operating system WindowsÒ Embedded CE 6.0 Prof.> Structure
