© 2003 Directed Electronics, Inc. Vista, CA 33
FEATURE DEFAULT - LED ON SETTING LED OFF SETTING
NUMBER (PRESS CHANNEL 1) (PRESS CHANNEL 2)
2-1 Engine check ON Engine check OFF
2-2 Tachometer engine check Voltage engine check
2-3 12 minutes run time 24 minutes, 60 minutes run time
2-4 Flashing parking light output Constant parking light output
2-5 Cranking time 0.6 sec. (1)* Cranking time 0.8 (2), 1.0 (3), 1.2 (4), 1.4 (5),
1.6 (6), 1.8 (7), 2.0 (8), 4.0 (9) sec.*
2-6 Voltage check high level Voltage check low level
2-7 Short run (turbo) 1 minute 3, 5, 10 minutes
2-8 Activation pulse: 1 (1) Activation pulses: 2 (2), 3 (3)
2-9 2nd Ignition output 2nd Accessory output
2-10 Accessory state during wait to start OFF Accessory state during wait to start ON
2-11 2nd status output NORMAL Rear defogger latch, rear defogger pulse
2-12 Anti-Grind ON Anti-Grind OFF
*NOTE: The numbers in parentheses indicate the number of times the LED will flash.
menu #2
