shutdown diagnostics
The unit has the ability to report the cause of the last shutdown of the remote start system.
To enter diagnostic mode:
1. Turn the ignition off.
2. Press and HOLD the Valet/Program switch.
3. Turn the ignition on and then off.
4. Release the Valet/Program switch.
5. Press and release the Valet/Program switch.
The LED will now report the last system shutdown by flashing for one minute in the following grouped patterns:
The LED will stop flashing when the ignition is turned on.
LED FLASHES SHUTDOWN MODE
One System timed out
Two Over-rev shutdown
Three Low or no RPM
Four Transmitter Shutdown (or optional push-button)
Six (+/-) Shutdown
Seven (-) Neutral safety shutdown
Eight Wait-to-start timed out
