USER MANUAL ENGLISH
8
COMPONENTS COMPONENTS WIRE ROD WIRE ROD
BAT 24V BATTERIES M1 BRUSH MOTOR RD1 RED/6AWG BN/BK BROWN/BLACK / 20AWG
CH BATTERY CHARGER M2 VACUUM MOTOR RD2 RED/10AWG BU1 BLUE/18AWG
EB1 CONTROL PANEL BOARD M3 DRIVE MOTOR RD3 RED/18AWG BU2 BLUE/20AWG
EB2 USB CHARGING ELECTRONIC BOARD SW1 EMERGENCY-STOP SWITCH RD4 RED/20AWG BU/BK BLUE/BLACK/20 AWG
EB3 DRIVE ELECTRONIC BOARD SW2 KEY SWITCH RD/BK RED/BLACK/20AWG GN GREEN/20AWG
RL1 BRUSH MOEOR ELECTROM SWITCH SW3 CLEAN WATER LEVEL SWITCH BK1 BLACK/6AWG GN/BK GREEN/BLACK / 20AWG
RL2 VACUUM MOEOR ELECTROM SWITCH SW4 VACUUM MOTOR SWITCH BK2 BLACK/10AWG GY GRAY/20AWG
RL3 DRIVE SYSTEM ELECTROM SWITCH SW5 OPTIONAL MODE SWITCH BK3 BLACK/12AWG PU PURPLE/20AWG
YV WATER ELECTROVALVE SW6-A OPTIONAL REVERSE SWITCH BK4 BLACK/14AWG OR ORANGE/20AWG
F1 CONTROL PANEL BOARD FUSE SW6-B OPTIONAL REVERSE SWITCH BK5 BLACK/18AWG YE YELLOW/20AWG
F2 BRUSH MOTOR CIRCUIT BREAKER SW7 SEAT SWITCH BN1 BROWN/14AWG WH1 WHITE/12 AWG
F3 VACUUM MOTOR CIRCUIT BREAKER SQ FOOT THROTTLE BN2 BROWN/20AWG WH2 WHITE/20AWG
F4 DRIVE SYSTEM CIRCUIT BREAKER SPK 12VDC BUZZER
F5 BRUSH RELEASE FUSE VR SPEED POTENTIOMETER
KA BRAKE
