25
USER MANUAL ENGLISH
6
TECHNICAL PARAMETERS
MODEL AS530R
Packing dimensions (Lx W x H) mm 1470*730*1310
Machine height mm 1120
Machine length mm 1360
Machine width (without squeegee) mm 580
Machine weight with empty tanks
(without batteries)
Kg 140
Gross vehicle weight (GVW) Kg 270
Shipping weight Kg 245
Solution tank capacity Liter 72
Recovery tank capacity Liter 73
Vacuum motor power Watt 400
Vacuum capacity mm H₂O 1223
Climbing capacity (Max) % 10
Front wheel diameter mm φ175
Rear wheel diameter mm φ230
Sound level dB(A) 69
Solution/water Flow L/min 0.84-2.0
Working width mm 530
Squeegee width mm 730
Brush/pad diameter mm 530
Brush motor power Watt 450
Brush speed Rpm 160
Brush/pad pressure (Max) Kg
Drive motor power Watt 300W
Working speed Km/h 5.5km/h
Voltage V 24V
Battery Ah 2x100AH (20 hours)
Battery charger V/A 24V 10A
Battery compartment size (L x W x H) mm 350*380*300
USB charger specification V/A 5V, 0.8A
