Viper Fang 18C User Manual

DIA
NO.
PART
NUMBER
DESCRIPTION
NO.
REQ'D
1
VF80111 FILTER, CLEAR DOME
1
2
VF82139 “O” RING
1
3
VF80113 FILTER
1
4
VV20501 SCREW, PH, SST, M5 X 14
2
5
VV13654 WASHER, SST, M5
2
6
VF80112 MOUNTING BASE, FILTER
1
7
VF82090 CLAMP, HOSE
5
8
VF80349 HOSE, INLET, FILTER
1
9
VF13521 NUT, M6
12
10
VF13533 WASHER, M6
12
11
VV13607 WASHER, LOCK, M6
12
12
VF13495 SCREW, M6 X 16
12
13
VF80123B AXLE, WHEEL
2
14
VF82113 BUSHING
2
15
VF80115B WHEEL, 6"
2
16
VF14257 NUT, NYLON INSERT, M16
2
17
VF80110 CHASSIS
1
18
VF80109 CONNECTOR
1
19
VV13604 SCREW, HEX, M8 X 20
4
20
VF14313 WASHER, INTERNAL TOOTH, M8
2
21
VF13514A
WASHER PLAIN M8
5
21
VF13514A
WASHER
,
PLAIN
,
M8
5
22
VF80130 WASHER, M8
4
23
VF80132 BUSHING
4
24
VF80216U SOLUTION VALVE, 110V
1
25
VF80238 HOSE, OUTLET, VALVE
1
26
VF80119A MOUNTING FRAME, VALVE
1
27
VA13483 WASHER, PLAIN, M4
2
28
VV20291 WASHER, LOCK, M4
2
29
VA13473 SCREW, PH, M4 X 16
2
30
VF80114 OUTLET FILTER
1
31
GT13022 NUT, NYLON INSERT, M5
2
32
VF80120 MOUNTING PLATE, FILTER
1
33
VV60220S1 SCREW, HEX SOCKET, M6 X 15
1
34
VF80207 WASHER, PLAIN BRASS
1
35
VF80240 KEY
1
36
VF80220 DRIVING PULLEY
1
37
VF13503 NUT, NYLON INSERT, M8
5
38
YCQ35000A MOTOR, 110V
1
39
VF80241 GASKET
1
40
VF14314 WASHER, EXTERNAL TOOTH, M8
2
41
GT13018 BOLT, M8 X 30
2
42
VF13513 NUT, M8
3
43
VF80206 SUPPORTING SHELF
1
44
VF80237 SPRING
1
45
VF14114 BOLT, M8 X 55
1
8
