Viribus atb-e024-bk - Installing Spoke Reflectors and Battery

16
14. Installing the Spoke Reectors
1. Fit the slots of one spoke reector (24) onto 2 spokes.
2. Press the reector until it is locked in place.
3. Install the other spoke reectors following the same steps.
15. Installing the Battery
1. Press the lever underneath the seat, moving the seat out of the way.
2. Slide the battery (3) into place behind the seat tube.
3. Replace the seat.
4. Insert the attached power plug into the socket.
