10. Installing the Rear Fenders, Supports, and Stays
Note:
The two sets of rear supports (7) and rear fender stays (21) are the same. They can be
used on either rear fender. The two rear fenders are the same. They can be used above either
rear wheel.
1. Remove the 4 bolts from the front and rear sides of one rear fender support. Place them
nearby.
2. Fit one rear fender onto the support, aligning their holes with each other.
3. Replace the bolts, tightening them with your Phillips screwdriver.
4. Remove the 2 bolts and slats from the top of the rear fender. Place them nearby.
5. Mount one rear fender stay onto the rear fender support.
6. Replace the slats and bolts, partially tightening the bolts with your Phillips screwdriver.
7. Remove the 2 bolts from the left and right sides of the rear fender support. Place them
nearby.
8. Turn the rear fender stay, aligning their holes with those of the support. Adjust its shape
using your pliers if needed.
9. Replace the bolts, tightening them with your Phillips screwdriver.
10. Lock the fender stay by tightening the bolts on the top completely with your Phillips
screwdriver.
