Viribus atb-e024-bk - Installing Pedals and Rear Reflectors

11
8. Installing the Pedals
Note:
The two pedals (14)
ARE
different and should
NOT
be mixed up. The right pedal is
marked with an
R
and the left with an
L
.
1. Attach the pedals to the crank arms on the appropriate side, screwing them into place.
2. Tighten their locking nuts with your 15mm wrench.
3. Test that the chain turns smoothly while using the pedals. Adjust as needed.
9. Installing the Rear Reectors
Note:
The two rear reectors (25) are the same. They can be used on either rear fender (8).
1. Remove the nut from one rear reector’s bolt. Place it nearby.
2. Attach the rear reector to a rear fender.
3. Replace the nut, tightening it with your pliers.
4. Install the other rear reector following the same steps.
