PARTS LIST
# Description Remark QT
1 Computer 1
2 Top cover of the console ABS 1
3 Bottom cover of the console ABS 1
4 Safety key 1
5 Support frame of the console Q235 1
6 Spring 2
7 Pull pin M8*15 2
8 Handrail foam 2
9 Washer M6 2
10 Self locking nut M6 4
11 Upright tubes Q235 2
12 Switch ABS 1
13 Supporting food pad M8*L30 2
14 knobs M12*81 2
15 Hexagon socket butt joint screw M6*30, φ10 2
16 Wheels φ8.1* φ50*T22-PU 2
17 Motor 1
18 Drive belt 170J5 1
19 Bottom motor cover ABS 1
20 Front roller 1
21 Self locking nut M6 2
22 Flange nut M8 6
23 Base frame Q235 1
24 Foot pad φ38*28-PP 2
25 Back roller 1
26 Philip’s head self drilling screw with pad ST4.2*16 6
27 Left end cap 1
28 Socket cap screw M6*55 3
29 Right end cap 1
30 Running plank MDF 8
31 Countersunk hexagon socket screw M8*40 6
32 Side rail ABS 2
33 Running belt 1
34 Cross recessed countersunk head tapping screw ST4*16 6
35 Top motor cover ABS 1
36 Power cord 1
37 Round pipe plug ABS 2
38 Pulse sensor ABS 2
39 IPAD-holder ABS 1
40
Philip’s head screw M3
2
