STEP 2
Use the M6 screws (the screw is pre-assembled on the upright tubes) to x the console together with the
upright tubes, then connect the connector wires of the right handrail and upright tube.
ASSEMBLY INSTRUCTIONS
Attention: There are wires on the front and back side of the connector. Be careful not to pinch the
wires. Also pay attention tot this when folding and unfolding when using the treadmill.
