Viscount CANTICUS I - II
35
12. Tutti (T):
The
Tutti
enables a series of preset registers which increase the intensity of the voice by enabling all the
registers which make up the rich sound of the "great organ".
•
N.B.:
The Tutti does not activate the modulation voices or the tremolos. The phonic composition of the TUTTI can be
programmed (see chapter 2).
13. Cancel button (C):
Press this button to switch off all organ registers in operation.
1.5 PEDAL SECTION CONTROLS
CANTICUS I
14. Man.II Pedal:
Expression pedal that control the second manual.
Also note that the expression pedals are fitted with a small circuit which simulates the action of the pipe box, reducing the
high tones at low volumes.
CANTICUS II
15. Crescendo pedal:
When this pedal is pressed, more and more registers are activated on all sections of the organ, when
it is rerouted, the number of registers will gradually be reduced. The Crescendo steps can be programmed. See chapt. 2 for
futher informations.
16. Man.II pedal:
This pedal can be used to control the volume of the second manual. If the ENC button under the first
manual has been pressed, this pedal can be used to control the overall volume of the organ. Also note that the expression
pedals are fitted with a small circuit which simulates the action of the pipe box, reducing the high tones at low volumes.
17. Couplers pistons:
These pistons enable the organ couplers.
18. Tutti piston:
Press this piston to recall the sound of the "great organ" or TUTTI. For further informations see "Controls
on manuals" section - "TUTTI button".
14
15
16
17
18
