Viscount Physisplus Series User Manual

EN - 15
Quick Guide
Selecting and regulating the voices (Voicing menu)
SELECTING AND REGULATING THE VOICES
(VOICING menu)
One of the main features of the Physis Plus synthesis technology is that it offers the user a wide array of options
for customising the instrument with a very large number of organ timbres, and also makes available several
parameters which can be adjusted to further increase the setup potential.
The VOICING menu contains all the functions for selecting and regulating the
voices’ audio parameters. To access to this menu, in the main video page,
1. press the [MENU/ENTER] button,
2. place the cursor on the VOICING field,
3. press [MENU/ENTER] or hold down/out for a few moments the tab (in the
ON position) or drawknob of stop you wish to edit.
Once you have entered the VOICING video page, you can select other stops to
edit, using the tab or drawknob in the same way explained above.
The Led of the stop being modified will flash to prevent modification errors; the stop will be on and can be
played for better, quicker adjustment. Other stops can also be switched on to assess the overall effect of the
changes.
The screen-printed on the drawknob or tab being edited is shown at the top of
the VOICING video page.
The SELECT VOICE field allow you to access to the list of alternative voices. In
this list the currently selected voice is indicated by the symbol. When the [ ]
and [ ] buttons are used to move the cursor to other voices, the symbol will
be moved as soon as the new voice can be played to be evaluated immediately.
Other stops can also be switched on to assess the overall effect of the changes.
Press [MENU/ENTER] to confirm the new voice and make it usable, press [EXIT]
to avoid the change and reselect the previous voice.
In the VOICING video page, below the SELECT VOICE field, are displayed the main sound generation
parameters of the selected stop. The parameters displayed are not the same for every voice, since some
families have specific setting parameters not required for other types of voice.
The settings which can be made are:
Parameter name
Description
Volume
Stop volume.
Settings: -12 dB to +12 dB
Attack
Attack time the sound takes to reach the maximum volume.
Settings: -4 to +4
Tremulant Type
Tremolo Type
Select which tremulant modulates the stop.
Settings:
 Off: tremulant is not applied to the stop.
 1st: 1st tremulant.
 *1st*: 1st tremulant automatically applied to the stop when it will be switched on.
 2nd: 2nd tremulant.
 *2nd*: 2nd tremulant automatically applied to the stop when it will be switched on.
Tremulant Sens.
Tremolo Sens.
How much the tremulant affect the stop.
Settings: 0 to 8
Ensemble Rescale
Rescaling of the overall ensemble set with the ENSEMBLE parameter (see page 14).
Settings: 0 to 8
NOTES
-
The voices selected for each stop and the sound generation parameters are automatically saved in the
current Pipe Set. This means that when another Pipe Set is recalled, the voices will be reset with new
parameters taken from the last Pipe Set recalled. The changes made earlier are not lost, and will be
made available when the style in which they were made is selected again.
-
While adjusting the VOICING parameters, in order to assign a voice to a stop and to adjust it, we
advice to select the desired voice first and then to adjust its generation parameters. Please do so, as
when a new voice is selected, its parameters are reset to default values.
