Viscount Physisplus Series User Manual

EN - 8
Quick Guide
Switching on and main video page
SWITCHING ON AND MAIN VIDEO PAGE
After turning on the instrument, the display shows the Physis Plus logo video page and, once ready, the main
video page:
containing the following display field:
 PIPE SET: Pipe Set currently in use (page 9).
 CMB: selected combination. The first two numbers indicate the memory bank, the third number (in reverse)
indicates the combination selected as showed by the illuminated general combination thumb piston.
 TRANSP: transposition set in TUNING (page 14).
 TEMPERAMENT: temperament currently in use, selected in TUNING (page 14).
 PITCH: instrument’s tuning, expressed as the frequency of A4, set in TUNING (page 14).
 CRESC: currently selected Crescendo step.
 EXPRES: expressions levels in according to the expression pedals position.
When the main page is displayed, [+] and [-] buttons can be used to adjust one of these parameters. To select
which parameter is adjusted, use the [ ] and [ ] buttons, “+” and “-“ symbols are displayed in the field of the
adjusted parameter. It is also possible to regulate the reverb level or no parameter, selecting these using [ ]
and [ ] (showed by a pop-up message).
How to navigate in the menus
Here a simple explanation how to display a specific video page, regulate a parameter and come back to the
main video page. Bear in mind this procedure to reach all the parameters described in the Quick Guide and
Reference Manual. Example: you have to regulate the general pitch at 439,19 Hz:
press the
[MENU/ENTER]
button to enter in
the MAIN MENU
press the
[MENU/ENTER]
button to enter in
the TUNING menu
press the
[EXIT] button
to leave the
TUNING menu
press the
[-] button
to adjust the
PITCH parameter
press the [] button to move
the cursor to PITCH parameter
press the [EXIT] button
to leave the MAIN MENU
