OTHER SOLUTIONS FROM VISION ENGINEERING
Product Picture Features Description
Kestrel
 150mm x 100mm stage
 QC-200 Microprocessor
 Eyepieceless viewing system
 Video Edge Detection option
Entry level, 2–axis measuring system.
Ideal for shop floor gauging applications.
Merlin
 150mm x 100mm stage
 x10 - x50 magnification options
 QC-300 Microprocessor
 Manual Video Edge Detection.
2-axis video measuring system with
touch screen video processor.
Powerful yet simple to use, ideal for a
wide range of gauging applications.
Hawk
Manual
 150mm x 150mm stage
 2 or 3 axis capability
 Large stage option
 Eyepieceless viewing system
 Video Edge Detection option
Advanced manual measuring system
offering increased accuracy and
capacity. Operates with QC-200 and
QC-300 microprocessors.
Hawk
Precision
 200mm x 150mm stage
 2 or 3 axis capability
 Eyepieceless viewing system
 Video Edge Detection option
High accuracy measuring system for 2
and 3 axis measurement. Operates with
QC-200 and QC-300 microprocessors or
QC-5000 PC software.
Hawk
Automatic
 200mm x 150mm stage
 Video Edge Detection option
 Motorised stage movement
 2 or 3 axis capability
Automatic measuring system combining
optical viewing head with PC based
Video Edge Detection. 2 and 3 axis
motorised stage movement controlled
by QC-5000 PC software.
Non-contact measuring systems
