1.2 Direct Connection to Computer
Direct Connection to Computer Using Crossover Cable
Once the machine or controller is connected directly to your computer's network port with the
crossover cable (the gray colored cable), turn the machine or controller on. The power switch for the
Vision Express is located on the power supply box for the machine. The power switch for the VE810 is
located below the LCD screen on the front of the machine. The power switch for the Vision Series 4
Controller is located on the front left of the Controller. Once the machine or controller has initialized,
plug the supplied Vision USB drive (or white/blue or orange USB Dongle) into an available USB port on
your computer.
NOTE - This installation is performed on a Windows 7 PC. For Windows XP, Windows 8, Windows 8.1
or Windows 10, the screens are slightly different.
The computer will recognize the USB drive
and the following screen will appear.
Select Continue without scanning.
Select Open folder to view files.
