Vision TC3-AMP - Rear Panel; Ir Remote Control

5
TC3-AMP_manual_en
REAR PANEL
1. Power Input (phoenix)
2. Input 2 (ground /left / right)
3. Speaker Outputs
4. Input 1 (ground /left / right)
5. IR receiver
IR REMOTE CONTROL
1. Power On / Off
2. Input 1 and 2
3. Volume up and down
4. Mute
Note: the remote is common to other
Vision products so some buttons such
as tone do not function with this product.
1
1
3
4
2
5
4
3
2
