User’s Manual
4
1.2 Front Panel
Name Function
1. Switch between operation and standby modes
2. IR Receive infrared remote control signal
3. DISPLAY Display status
4. MENU Display/exit from main menu
5/9. Adjust volume or move cursor left/right
6. OK Display channel list or confirm operation
7/8. Switch channels or move cursor up/down
10. USB slot Connect to specific USB device
11. Smart card slot Open the cover to insert smart card
1.3 Conditional Access (CA)
With smart card, you can enjoy various programs of channels scrambled by Irdeto.
Note: The smart card is provided by your local operator.
Insert Smart Card
Open the right-hand cover on front panel.
Face the side with electronic chip downwards and insert
the smart card into the upper slot horizontally according to
arrow direction.
Notes:
Only FTA channels are available without the smart
card.
Don’t attempt to remove or insert the smart card while the receiver is on.
