10
Installation (continued)
4
Install Adhesive Foam Seal
□ Cut the adhesive Foam Seal A (II) and B (DD) strips to the proper lengths, and attach them to the window sash and frame as
shown.
DD
DD
DD
DD
DD
DD
II
II
II
II
II
II
5
Install Window Slider
□ Insert the window slider (GG and HH) assembly into the window opening.
GG
GG
HH
HH
6
Cut Foam to Length
□ Cut the non-adhesive Foam Seal C (EE) strip to match the width (or height) of the window. Insert the seal between the glass and the
window frame to prevent air and insects from getting into the room.
EE
EE
To Next Page
