Installation (continued)
7
Install Security Bracket (optional)
□ Install the security bracket (FF) with 2 screws as shown.
8
Install Window Slider Adaptor
□ Insert the window slider adaptor (CC) into the hole of the window slider (GG).
NOTE: To ensure proper function, DO NOT overextend or bend the hose. Make sure that there is no obstacle around the air outlet of the
exhaust hose (in the range of 500mm) in order to the exhaust system works properly. All the illustrations in this manual are for explanation
purpose only. Your air conditioner may be slightly different. The actual shape shall prevail.
FF
FF
To Next Page
