14. Technical Specication
Product Vitalograph Compact
Model 6600
Flow Detection Principal Fleisch type pneumotachograph
Volume detection Flow integration sampling @ 100Hz
Volume Accuracy ±2.5%or±0.05L
Flow Measurement Range Max.owrate±960L/min(±16L/s)
Min.owrate±1.2L/min(±0.02L/s)
PEF Accuracy ±10%or 0.3 L/s
Back pressure of Fleisch
Flowhead
Less than 0.1kPa/L/sec at 14L/sec
Operating Pressure RMS +/- 300cmH20
Pressure Accuracy RMS +/-3%
Pressure Resolution RMS 1 cmH20
Operating temperature
range
ISO 26782:2009 Guidelines: 17–35ºC
Design limits: 10–40ºC
Operating humidity range 30%–75%
Operating ambient pressure
range
850hPa–1060hPa
Performance standards
the Vitalograph COMPACT
meets or exceeds
ISO23747:2015,ISO267822009,ATS/ERS2019
Safety standard EN60601-1:2006 + A1:2013 + A2:2021 + A2:2021
EMC standard EN 60601-1-2:2015 + A1:2021
QA/GMP standards EN ISO 13485:2016, FDA 21 CFR 820, CMDR
SOR/98-282 & Japan’s PMD Act
Dimensions 296 x 261 x 108 mm
Weight 3 kg net
Communications USBx6,Ethernetx2,Wi
Power Supply 19V DC Power Supply
Operating System Windows 10 Embedded
Processor Intel Quad Core Processor
RAM 4GB
Screen 12.1” LCD 1280*800 pixel with capacitive touch
screen

Vitalograph Compact Specifications

General

Brand	Vitalograph
Model	Compact
Category	Medical Equipment
Language	English
