3.1. Features of the Vitalograph Compact
• Medical workstation running Vitalograph Spirotrac Software
• Spirometryowhead(FleischPneumotachograph)
• Respiratorymusclestrength(RMS)owheads(optional)
• Touch screen colour display
• Audio feedback
• Connectivity for devices integrated with Spirotrac software
• Automatic storage of all test data
• Networked database (optional)
• Sniff nasal inspiratory pressure (SNIP) measurement
• Adjustable leg to change viewing angle of display.
4. Setting Up the Vitalograph Compact
1. AttachtheowheadtotheVitalographCompactusingthesiliconetubing
(Flowhead Connection Tube). The tubing is keyed so that it may only be
inserted in the correct orientation.
2. Ifrequired,attachtheMIPorMEPowheadtotheVitalographCompact
by the tubing supplied. Ensure that the clear end of the tube is connected
to the RMS Connection porton the Compact, adjacent to the spirometry
connector. The white silicone tube on the other end of the tubing is attached
totheconnectorontheMIPorMEPowhead.
Note: The push in connector on the connection port should be pushed
 rmlyandsquarelyagainstthefaceoftheconnectorwhenconnecting/
 disconnectingthetubing.Connectotherendoftubingtotheowhead.
3. If required, attach the SNIP nasal probe adaptor to the RMS connection port
on the Compact. Fasten the SNIP nasal probe to the adaptor.
Note: The push in connector on the connection port should be pushed
rmlyandsquarelyagainstthefaceoftheconnectorwhenconnecting/
disconnecting the tubing.
4. Ifrequired,attachtheWidongle(16)intoanavailableUSBportonthe
back of the device (3) (see Figure 1).
5. The leg may be adjusted to change the viewing angle of the display.
6. Connect the jack plug from the power supply into the socket at rear of the
Compact. Plug the mains plug into a suitable socket, operate the On/Off
button on the side of the instrument. The Compact is ready for use.
Note: Only use the Compact with the purpose-built low voltage power
supply with which it is supplied.
7. Use the Launcher to open the Spirotrac application, add Ethernet, WiFi,
printers. Contact Technical Support for approved installation assistance.
8. For guidance using Spirotrac software on the Compact refer to the Spirotrac
Instructions For Use available on the device, in the ‘’i’ (information) option in
the menu on the left side of the Spirotrac application.
9. For guidance installing the Vitalograph Connect Software, please refer to
the Connect Instructions for Use on the USB Key. Connect will need to be

Vitalograph Compact Specifications

General

Brand	Vitalograph
Model	Compact
Category	Medical Equipment
Language	English
