Vitalograph COMPACT - Instructions for Use
3. Main Components of the Vitalograph Compact
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Figure 1. Main components of the COMPACT
1 Power Supply
2 Stylus
3
I/O Ports - 6 x USB, 2 x Ethernet, 2 x Display Port
Powerconnection,RMSport(MIP/MEP/SNIP)andowheadport
4 Flowhead
5 Flowhead Connection Tubing
6 Bacterial Viral Filter (BVF)
7 Flowhead Carrier
8 Colour LCD and Touch Panel Display
9 Power Switch
10 MIP/MEP Pressure Vent
11 MIP/MEP Flowhead Connection tube
12 MIP/MEP Flowhead
13 SNIP Nasal Probe
14 SNIP Nasal Probe Adaptor
15 Adjustable Leg
16 WiFi dongle (not pictured)
17 USB key with Connect Software (not pictured)
