INSTALLATION
6 CHAPTER 1
1.4 CONNECTIONS
1.4.1 GENERAL
See for connection specifications the “install sheet” at the end of this chapter.
1.4.2 ELECTRICAL CONNECTION
Only qualified electricians should work on the electrical circuits of the machine.
1. Connect the mains leads in accordance with the diagrams.
Check the Current rotation of the phases. The current rotation of the phases L1, L2, L3 must be
clockwise.
2. Block the mainswitch in the “OFF” position with a padlock to prevent dangerous situations.
1.4.3 NITROGEN CONNECTION
1. Connect the supply hose to the hose connector at the rear outfeed side of the machine.
1.4.4 EXHAUST SYSTEM
One exhaust gauge of 160 mm (6.3”) is provided. This should be connected with the customer’s
exhaust system (not supplied by Vitronics Soltec).
• Inflammable and/or explosive gas might develop in the machine because of the evaporation of
the solvent in the flux.
• An exhaust system that functions well, will bring the gases below the explosion concentra-
tions.
• It is therefore necessary to have a sufficient exhaust in the machine.
• The exhaust system also has to be checked continuously on its well functioning.
• The machine is prepared to interfere in the E-stop circuit of the machine with a potential free
contact of the exhaust system. This contact has to be normally open, and therefore closed
when the exhaust functions well (fail safe).
NEVER USE THE MACHINE WITHOUT THE EXHAUST SYSTEM.
1.4.5 PERSONAL COMPUTER
The complete Personal Computer is packed in boxes for transporting. Unpack all boxes and put
the PC in the machine, and the monitor and keyboard on the PC-arm. Connect all cables.
