20. Behavior of Thermostat on voltage failure,
recovery and commissioning.
21. Control Panel
Behavior on bus voltage failure
On failure of bus voltage no actions are executed by
the device; behavior of controlled actuators must be
set using their own parameters.
Behavior on bus voltage recovery
On bus voltage recovery all the communication
objects are set to 0 except for objects for which a
parameter is de ned for the initial value.
Thermostat keeps these values in memory and restore
them after recovery:
• Heat / Cool mode (if enabled)
• HVAC Mode (if enabled)
• Base Setpoint (if enabled)
• Force value in manual mode (if enabled)
Control values (i.e. commands to actuators) are cal-
culated on the base of actual setpoint and measured
temperature.
• After power on device recalculates the com-
mands to actuators and switch them on, if necessary,
otherwise does not carry out any action; you are
recommended to set the behavior of actuator in order
to switch the heating / cooling equipment o after
bus power on.
Behaviour on commissioning (ETS Download)
After download it is possible to set initial value of:
• Heat / Cool mode (if enabled)
• HVAC Mode (if enabled)
For other communications objects the behavior is
identical to bus voltage recovery.
Wrong application download
If the wrong ETS application is downloaded then KNX/
EIB led starts blinking and device is not operative on
the bus. A power reset must be done and the correct
ETS application must be downloaded.
The operator panel mode is used when the device
behaves as a user interface while the temperature
control function is delegated to another device or to
a subsystem that communicates with the operator
panel via the KNX bus
Communication object what can be written on the
KNX bus (can be used all or some):
• Temperature Alarm
• Actual Temperature
• Actual Setpoint
In this Mode the three capacitive buttons continue to
work normally. [1]
[1]: functions freely con gurable can be used to
manage the type HVAC controls, the speed of the fan
coil, or various commands such as ECO; DND, MUR,
OFF; etc ..
Communication object what can be read on the KNX
bus (can be used all or some):
• Actual Temperature (from another KNX devi-
ce)
• Setpoint Adjustment (1 bit or 1 byte object
that permits the adjustment “-“/”+” of the sepoint)
