Vitrum Clima - Right Button Configuration; Central; Left Button; Activation on Press; Edge

SIMPLY INIMITABLE.
6
Number of byte values
Function
Value <x> [1..9]
4. Right button conguration
5. Central / Left button
6. Activation on press / edge
The right button of the glass room temperature
controller can be congured to perform the “fun-
ction mode” or “nothing”
For each of the two button, present on the device, the se-
lections are made through a conguration page.
Every single button can be congured to perform one of the
following functions:
• Nothing
• Activation on press
• Activation on short and long press
• Dimming
• Shutter and blinds
• Scene
• Command in sequence (on short and long press)
• Command in sequence (toggle mode)
The “Activation on edge “ allows you to congure
the sending of telegrams when the button is pres-
sed or released
You can set to send a telegram with dierent va-
lues associated with dierent edges, or decide to
send commands only one of the two edges
With the “Activation of the press” selection device
can also be congured to send periodic messages
with repetition period.
KNX PARAMETER
KNX PARAMETER
SETTINGS
SETTINGS
Function
Minimum time long
press input
nothing
function
mode
0,3 sec
0,5 sec
0,8 sec
1,0 sec
2,0 sec
3,0 sec
5,0 sec
10 sec
2-9
Nothing
Activation on press
Activation on short and
long press
Dimming
Shutter and blinds
Scene
Command in sequence
(short/long press)
Command in sequence
(toggle mode)
0-255
Select the number of byte values used in the “fun-
ction mode” function.
Select the corresponding value to be assigned to
the value <x>
If function mode is selected, “number of byte values”
parameter is displayed.
When “function mode” is enable each press sends
the next byte of the sequence set
Determines how long must be a press to be consi-
dered long; if shorter than the selected value the
press will be considered short.
Nothing
When the capacitive button is pressed no
action are made
Activation on press
see par. 5.1- Activation on press
Activation on short and long press
see par. 5.2-Activation short/ long press
Dimming
see par. 5.3- Dimming
Shutter and Blind
see par. 5.4- Shutter and Blind
Scene
see par. 5.5 - Scene Management
Command in sequence
see par. 5.6 - Command in sequence
KNX PARAMETER SETTINGS
Telegram Associated
1 byte
1 bit
It is possible to send 1 bit or 1 byte objects
