10
4. 1 Measurement functions
4. 2 ATS control functions
Type Display Range Precision
Commercial power voltage
130 ~ 270 V ± 3 %
Emergency power voltage
130 ~ 270 V ± 3 %
Commercial power frequency
40 ~ 70 Hz ± 0.2 Hz
Emergency power frequency
40 ~ 70 Hz ± 0.2 Hz
VITAC 200 provides measurement and ATS control functions, and major parameters related to ATS
control can be modified using engineering software.
The single-phase voltage and frequency of the commercial and emergency power can be measured.
The following table shows the measurement range and precision.
VITAC 200 supports the W-Type and WN-Type ATS of VITZRO and various ATS of other suppliers.
If VITAC 200 is used with the 3Position ATS (as the WN-Type ATS of VITZRO), use the same wiring
method with the WN-Type of VITZRO.
4. Major functions
4. 2. 1. Manual switchover function
Switchover is performed manually using buttons located in the front. Please take the following
steps to perform switchover.
Step 1. Set manual mode
Check the “Auto/Manual status display LED”. If the mode is Auto (red lamp on), press and hold the
“Auto/Manual selection” button until the mode is changed to Manual (green lamp on).
Step 2. Perform manual switchover
①
Manual switchover from the emergency power to the commercial power
Press and hold the “Emergency power side switch on” button more than 1.5 seconds to change over
to the emergency power side.
However, switchover operation will be performed only when the emergency power is normal
(green lamp on the emergency power status display LED) and the LED status will be changed as follows.
- Switch status LED at the commercial power side: Changes from green to red.
- Switch status LED at the emergency power side: Changes from red to green.
②

Manual switchover from the commercial power to the emergency power
Press and hold the “Commercial power side switch on” button more than 1.5 seconds to change over
to the commercial power side.
However, switchover operation will be performed only when the commercial power is normal
(green lamp on the commercial power status display LED) and the LED status will be changed as follows.
- Switch status LED at the commercial power side: Changes from red to green.
- Switch status LED at the emergency power side: Changes from green to red.
