Vivax ACP-09CH25AERO - Page 9

7
L
R
H
Model
L(mm)
R(mm)
H(mm)
Dimension of
installation hole(mm)
ACP-09CH25AERO/I
170
92
45
65
ACP-12CH35AERO/I
170
95
45
ACP-12CH35AEXO/I
ACP-18CH50AERO/I
80
100
45
Model
L(mm)
R(mm)
H(mm)
Dimension of installation
hole(mm)
ACP-24CH70AERO/I 2
93
163
45
65
L
R
