– 5 –
ITEM LABEL DESCRIPTION SEE PAGE:
15.
12V
When connected to the screen through a commercially available cable, the screen
deploys automatically on start up of the projector. The screen retracts when the
projector is powered off (see notes below).
16.
AUDIO IN L/R
RCA (YPbPr)
Connect the audio cables from a audio device
17.
AUDIO OUT Connect an AUDIO cable for audio loop through
18.
AUDIO IN L/R
RCA (Video/ S-
Video)
Connect the audio cables from a audio device
19.
VIDEO Connect the composite cable from a video device
20.
S-VIDEO Connect the S-video cable from a video device
21.
YPbPr Connect a component video enabled device
22.
BNC Connect a BNC cable from a computer
23.
AC IN Connects the power cable
24.
Power switch Turns on/off the projector
13
25.
Security chain lock Helps protect the projector from unauthorized use
26.
Kensington Lock
Secures to permanent object with a Kensington® Lock sys-
tem
43
Note:
y
To use this feature, you must plug in the connector before turn on/off the projector.
y
Screen controllers are supplied and supported by screen manufacturers.
y
Do not use this jack for anything other than intended use.
Note:
If your video equipment has both S-VIDEO and RCA jacks (composite video) connect to the
S-VIDEO connector. S-VIDEO provides a better quality signal.
Warning:
As a safety precaution, disconnect all power to the projector and connecting devices before making
connections.
